设计

2-driver, 2-way in-ceiling, SHOCK-MOUNT™ Isolation Mounting System, nylon-blended rigid baffle

分频器

3nd-order electro-acoustic at 2.0 kHz

频率响应  On-Axis

±3 dB from 60 Hz - 22 kHz

频率响应  30°离轴

±3 dB from 60 Hz - 18 kHz

高音单元

1" (2.5cm) X-PAL™ dome, ferro-fluid damped / cooled, Reduced Edge Diffraction (RED™) Technology, Perforated Phase-Aligning (PPA™) Tweeter Len

中/低音单元

8" (20.3cm) X-PAL™ driver, overmolded Active Ridge Technology (ART™) surround, 1.5" high-temp voice coil, die-cast aluminum chassis

低音下潜

37 Hz (DIN)

灵敏度   房间/消声室

93 dB / 89 dB

阻抗

Compatible with 8 ohms

合适的放大器功率范围 Range

15-160 W

最大输入功率

100 W

颜色

White, paintable grille, black speaker

重量

6.4 lbs. (2.9 kg)

Cut-Out Dimensions

9.1875" (23.4cm) Diameter

总尺寸

10.25" (26.1cm) Diameter

最小安装深度

3.875" (9.8cm)
